Available in six configurations, able to grind and lap gate and check valve seats and resurface seat areas to original manufacturer specifications or better. A tilting adapter is included to ensure quick and easy adjustment of grinding pressure.
Valve Grinding & Lapping Machine – VM1000 Series
Mobile Nav
| Product Name | Seat Diameter Range | Submerging Depth | Valve Type | Power Option |
| VM1150 | 1.25″ – 6″ (32 – 150 mm) | 16″ – 18″ (400 – 450 mm) | Gate or Swing Check | Electric or Pneumatic |
| VM1350 | 1.5″ – 14″ (40 – 350 mm) | 24″ (600 mm) | Gate or Swing Check | Electric or Pneumatic |
| VM1600 | 1.5″ – 24″ (40 – 600 mm) | 39″ (1000 mm) | Gate or Swing Check | Electric or Pneumatic |
POWERFUL PERFORMANCE
- Robust drive system uses a drive chain up to three sizes larger than the competition, with a Mean Time Between Failure (MTBF) of approximately 10,000 hours. This minimizes the risk of breakage and costly downtime on the job.
- Five Planet Arms ensures that no two discs are ever directly across from each other and carrying the entire workload. All of the discs are in contact with the work surface, eliminating development of high and low spots on valve seat.
- High-quality abrasives can help reduce grinding time by up to 50%.
- Heavy-duty drive chains provide a minimum of 10,000 hours of service.
VERSATILITY
- Strong adhesive media discs are specifically formulated to provide a firm hold while in use, but are easy to remove after use.
- Quick changeover between electric and pneumatic by simply loosening a single clamping bolt.
- Four configurations with seat diameters ranging from 1.25 – 24 inches (32 – 600 mm).
- Submerging depth up to 39 inches (1000 mm).
- Quickly change from grinding to lapping operations by simply changing the discs.
RELIABILITY
- Rigid planet arms eliminate machine chatter and ensure a uniform finish.
- Sealed planet arm bearings eliminate grinding and lapping grit, increasing the bearings’ life.
- Planet arm is preloaded and preset to be within .000079 inches (.002 mm) of each other, improving the finish flatness of the valve seat.
- Modular components make setup quick and easy.
- Factory-sealed bearings for fast, easy grinding head change-out.
- Planet Arms features one screw adjustment to quickly adjust the diameter size.
- CE Certified for use in the European Union or any country where CE certification is required.
